Filter Disc

Filter Disc:

Our Filter Disc is a high-efficiency filtration component precision-manufactured from multi-layer stainless steel sintered mesh, featuring excellent rigidity, uniform filtration accuracy, and reusability. It is widely used in pharmaceutical, chemical, food and beverage industries for solid-liquid separation, impurity removal and material purification in three-in-one and two-in-one equipment, with fully customizable specifications to meet diverse industrial filtration needs.

As a core filtration component in the global industrial filtration field, the Filter Disc has gained widespread recognition for its stable performance, strong adaptability and long service life, gradually replacing traditional filter cloths in many key production processes. Different from ordinary flat filter discs, our Filter Disc is crafted from high-quality multi-layer stainless steel sintered mesh, which is welded with flanges to form integral or split structural designs, ensuring structural integrity and reliable filtration efficiency. Made of premium SUS304 and SUS316L stainless steel, it exhibits exceptional corrosion resistance, high-temperature tolerance and mechanical strength, adapting to harsh working environments such as high pressure, corrosive media and frequent cleaning. Compatible with various three-in-one and two-in-one equipment, it is widely applied in pharmaceutical, chemical, food and other industries, providing efficient and stable filtration solutions for solid-liquid separation, impurity removal and material purification. This article comprehensively introduces the core features, regular specifications, key industry applications and usage methods of the Filter Disc, integrating all core keywords to help overseas customers quickly grasp product value and apply it to actual production.

1. Core Features of Filter Disc

Our Filter Disc combines the advantages of multi-layer stainless steel sintered mesh and precision manufacturing technology, with outstanding performance that outperforms traditional filtration materials, becoming the preferred choice for industrial filtration:

8226. Superior Rigidity & High Mechanical Strength: The multi-layer stainless steel sintered mesh structure, combined with professional flange welding technology, endows the Filter Disc with excellent rigidity and mechanical strength. It can withstand high-pressure filtration and stable installation, without deformation or damage even in harsh industrial environments, eliminating the drawbacks of poor rigidity and easy damage of conventional filter cloths.

8226. Uniform Filtration Precision & Reliable Performance: The filtration precision is precisely controlled within the range of 1~300μm, with uniform pore size distribution of the multi-layer sintered mesh, ensuring consistent and reliable impurity interception. It can effectively separate solid particles from liquids or gases, avoiding uneven filtration caused by inconsistent pore sizes, and maintaining stable filtration effect for a long time.

8226. Reusable & Easy to Clean: The Filter Disc supports multiple cleaning methods including countercurrent washing, filtrate rinsing, ultrasonic cleaning and baking, which can quickly remove trapped impurities and restore filtration performance. Its reusable design significantly extends service life, reducing procurement and replacement costs for enterprises, and is more cost-effective than disposable filter materials.

8226. Simple Assembly & Low Maintenance: Adopting a user-friendly flange connection design, the Filter Disc is easy to install, disassemble and replace, minimizing equipment downtime during maintenance. Its robust structure reduces the frequency of replacements, lowering long-term operational and maintenance costs for enterprises.

8226. Broad Environmental Adaptability: Crafted from SUS304 and SUS316L stainless steel, the Filter Disc has a working temperature range of -200℃~480℃ and can withstand working pressure up to ≤3.2MPa. It exhibits excellent corrosion resistance to weak acids, alkalis, organic solvents and other corrosive media, adapting to diverse filtration scenarios in pharmaceutical, chemical and food industries.

8226. Versatile & Customizable: We can customize the diameter, thickness, filtration precision, structure type (integral/split) and flange specifications of the Filter Disc according to customer needs. It is compatible with various three-in-one and two-in-one equipment, perfectly fitting different industrial filtration scenarios.

2. Regular Specifications and Parameters

We adopt standardized production processes and strict quality control (passing ISO 9001, CE and SGS certifications) to ensure the consistency and stability of product specifications. The following are the regular specifications and parameters of the Filter Disc, which can be fully customized according to customer actual filtration needs and application scenarios:

Note: The above are standard specifications. We can adjust parameters such as filtration precision (1~300μm), diameter (up to 3000mm), thickness, structure type and flange specifications according to your specific filtration requirements. The product can be supplied as finished filter discs or semi-finished products, and the minimum order quantity can be customized. The packaging adopts moisture-proof bubble wrap + fumigated wooden case to ensure safe transportation during international shipping. We also provide free installation guidance and usage training to assist customers in efficient application.

3. Key Industry Applications and Usage Methods

Our Filter Disc has excellent comprehensive performance and diverse usage scenarios, covering almost all fields of industrial filtration. It is mainly used for solid-liquid separation, impurity removal and material purification, providing efficient and stable filtration solutions for various industries. The specific applications and usage methods are as follows:

3.1 Pharmaceutical Industry

In the pharmaceutical industry, the Filter Disc is an essential component for three-in-one and two-in-one equipment, mainly used for filtration, washing and drying of pharmaceutical intermediates, powders and granules, as well as impurity removal in drug production processes. SUS316L stainless steel filter discs are preferred for their excellent corrosion resistance and compliance with GMP, FDA and other pharmaceutical hygiene standards. Usage Method: Install the filter disc in three-in-one/two-in-one equipment for solid-liquid separation of pharmaceutical materials; after filtration, clean the disc using ultrasonic cleaning or baking methods to remove residual materials, ensuring no cross-contamination between batches. Regularly inspect the filter disc for damage and replace it when necessary to maintain filtration precision and product quality.

3.2 Chemical Industry

In the chemical industry, the Filter Disc is extensively applied in chemical production for impurity removal in reaction liquids, purification of chemical raw materials, solid-liquid separation in process flows and catalyst recovery. It is compatible with various three-in-one equipment, effectively handling corrosive media (acids, alkalis, organic solvents) and high-pressure filtration scenarios. Usage Method: Select SUS316L filter discs for processes involving corrosive chemicals and SUS304 filter discs for general applications; install the disc in the equipment's filtration unit, ensuring tight connection with flanges to prevent leakage. When the pressure difference increases significantly or filtration efficiency decreases, perform countercurrent washing or ultrasonic cleaning to restore performance, extending the service life of the filter disc.

3.3 Food & Beverage Industry

In the food and beverage industry, the Filter Disc is used for purification of food raw materials, filtration of beverages (juice, beer, dairy products), edible oil refining and solid-liquid separation of food additives, meeting food safety and hygiene requirements. Made of food-grade SUS304/SUS316L stainless steel, it is non-toxic, odorless and easy to clean, complying with international food safety standards. Usage Method: Install the filter disc in two-in-one filtration equipment for impurity removal in food and beverage products; after use, rinse thoroughly with clean water or neutral detergent to remove food residues, and dry it for reuse. For high-precision filtration requirements (such as beverage clarification), select filter discs with 1~5μm precision to ensure product clarity and quality.

3.4 Other Industrial Fields

Beyond pharmaceutical, chemical and food industries, the Filter Disc is also widely used in petroleum refining, water treatment and mechanical engineering fields. In petroleum refining, it is used for impurity removal in lubricating oil and fuel; in water treatment, it serves as a key component for solid-liquid separation in industrial wastewater treatment; in mechanical engineering, it filters hydraulic oil and lubricating oil to protect precision equipment. Usage Method: According to specific application scenarios, select the appropriate material and precision; for high-temperature and high-pressure environments, use integral-type filter discs for enhanced structural stability; for scenarios requiring frequent maintenance, choose split-type filter discs for easier cleaning and replacement.

4. Product Advantages and Why Choose Us

As a professional manufacturer of Filter Discs, we have more than 15 years of R&D and production experience, focusing on providing high-quality filtration components and personalized solutions for global industrial customers. Our product advantages are as follows:

8226. Strict Quality Control: We use only high-quality SUS304 and SUS316L stainless steel multi-layer sintered mesh as raw materials, and each production process—from material selection, cutting, pleating to welding and inspection—is subject to strict quality supervision. All products meet international industrial standards, ensuring reliable performance and consistent quality.

8226. Advanced Production Technology: We have a professional R&D team and mature production technology, adopting precision welding and sintering processes to ensure the uniform pore size, firm structure and stable performance of the Filter Disc. We continuously optimize the production process, improving product performance to meet the high-demand filtration needs of customers.

8226. Professional Customization Capability: We can customize the Filter Disc according to the customer's filtration precision, working environment, equipment size and flange specifications. We provide one-stop solutions from product design, sample production to finished product delivery, solving personalized needs and reducing procurement and processing costs.

8226. Global Service & Timely Delivery: We have rich export experience, with products exported to Europe, America, Southeast Asia, Australia and other regions. We provide professional English technical support and after-sales service, customize packaging and delivery solutions according to the needs of customers in different countries and regions, ensure timely delivery (3-20 working days depending on quantity) and safe transportation, and establish long-term and stable cooperative relations with customers.

The Filter Disc, as a high-performance, multi-functional and widely applicable filtration component, has become an indispensable core product in the global industrial filtration field. With its excellent rigidity, uniform precision, reusable characteristics and broad adaptability, it provides efficient and stable filtration solutions for various industries. Whether you are engaged in pharmaceutical, chemical, food and beverage or other industries, we can provide you with the most suitable Filter Disc products and professional technical support. Welcome to contact us for more product details, quotes and free samples, and we look forward to cooperating with you to create a better future!
